Double Drive Table Type 1500*3000mm Cnc Plasma Cutter

Product Categories

Hyzont(Shanghai) Industrial Technologies Co.,Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: Double Drive Table Type 15003000mm Cnc Plasma Cutter
Brand: Hyzont
Price: 1 USD

Brand Name : Hyzont

Model Number : CNCTG-3015

Certification : CE

Place of Origin : Shanghai

MOQ : 1sets

Payment Terms : T/T, L/C, Western Union, MoneyGram

Supply Ability : 100 sets / Month

Delivery Time : 10 days

Packaging Details : wooden case

name : 1500*3000mm Cnc Plasma Cutter

type : Table Type

model : CNCTG-3015

certification : CE

Contact Now

Technical Specification

1 Model: CNCTG1530 table type plasma cutting machine

2 Basic components

Mechanical Components	Longitudinal rail type	24KG rail
	Plasma cutting torch	1set(Hypertherm)
	Plasma torch height controller	1set
	Plasma torch anti-collision device	1set
	Drive model	Double-drive
	Gas and hose supply type	Pedrail
Electronic Components	CNC controller	LKNC-3200
	Plasma torch anti-collision device	1set
	PLC	Delta(Taiwan Brand)
	Electric components	Schneider(France Brand)
	AC servo motor system	Panasonic(Japan Brand)
	Gear box	NEUGART(Germany Brand)
	Program and nest software	FASTCAM(Australia Brand)
	Plasma source	Hypertherm PowerMAX105
Auxiliary Machinery By Buyer	Voltage-stabilizer	We will supply requirement details
	Air compressor
	Oil-water separator

3 Main Specification

Basic Parameter	Effective cutting width	1500mm
	Effective cutting length	3000mm
	Plasma cutting thickness	1-16mm
	Plasma cutting speed	50-9000mm/min
	Cutting torch lifting distance	80mm
	Idle running speed	0-12000mm/min
	Speed setting error	≤±5%
	Torch height controller accuracy	≤±1.0mm
	Longitudinal line accuracy	±0.2mm/10m
Accuracy Test	Complete machine accuracy (Subject to the right drawing) Side length (Four sides) 1000mm x1000mm Lineation speed,500-800mm/min	A B C D
	length of a side	±0.5mm
	Diagonal error \|AD-BC\|	±0.5mm
	Base point return error	±0.2mm
	Intersection point error	±0.5mm
	Lineation forward- reverse error	±0.2mm
	Plasma power source	Hypertherm PowerMAX105
Plasma Part	Duty cycle	100%
	Max output current	100A
	Plasma source power	20KW
	Machine weight	3.2 ton
Other Parameter	Accelerated speed	≥ 0.6m/sec2
	Noise	≤80 db

4 Working requirement:

Basic Requirement	Supply power voltage/ frequency	3 phase×380v±10%/50Hz 1 phase×220v±10%/50Hz
	Ambient temperature	-10℃-50℃
	Relative humidity	<90% no condensation
	Surroundings	Ventilate
Plasma cutting requirement	Compressed air	Dry, Oil free; Flow: 400 scfh Pressure: 8 bar
